MSMA012A1G

★ ★ ★ ★ ★ Rated 0/5 Based on ratings.

Rate your purchase of the MSMA012A1G

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

New

$790

1 In Stock

✓  2 Year PDF Supply Warranty

*Need a Specific Revision?

The MSMA012A1G motor is part of the MSMA series, and it is a low-inertia digital AC servo motor manufactured by Panasonic. These servo motors are widely used in industrial automation systems for precise and controlled motion applications. The MSMA012A1G servo motor has a rated output power of 100W, indicating its ability to deliver consistent and reliable performance. It operates on a power supply voltage rating of 200V, which is a common voltage level in industrial applications. The motor is designed to operate at a rated torque of 0.32 Nm, enabling it to generate sufficient force for various application tasks. It has a rated speed of 3000 rpm (revolutions per minute), and this is the rotational speed at which it operates under normal conditions. Additionally, it has a maximum speed rating of 5000 rpm that allows for higher-speed movements when necessary. The current rating for the MSMA012A1G is specified as 1.6 A, and this is the nominal current level required for its operation. It can handle a maximum current rating of 6.9 A, which indicates its capability to handle temporary overload conditions without compromising performance. The motor is equipped with an encoder that has a resolution of 2500 p/r (pulses per revolution) to provide precise feedback for accurate position control. This allows the motor to achieve high levels of accuracy and repeatability in its movements. The MSMA012A1G motor has a shaft with a keyway that enables secure and precise connection to other mechanical components or loads. It also includes an oil seal to protect it from oil and to ensure long-term reliability and durability.

Technical Specifications for MSMA012A1G

Model Type:Digital AC Servo Motors
Series:MSMA Low-inertia Digital AC Servo Motors
Rated Output:100W
Power Supply:200V
Rated torque:0.32 Nm
Rated Speed:3000 rpm
Maximum speed:5000 rpm
Rated current:1.6 A
Maximum current:6.9 A
Encoder:2500 p/r incremental
Shaft:Shaft with keyway
Oil seal:Supported
