IC200PWR101

★ ★ ★ ★ ★ Rated 4.5/5 Based on 7 ratings.

Rate your purchase of the IC200PWR101

SKU 2173460  UPC 0799705798526

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

New Surplus

$525

2 In Stock

✓  3 Year PDF Supply Warranty

*What is New Surplus?

Ships .

Reman

$444

Save $81

28 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Repair Service

$356

Save $169

5-10 Days

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Repair Completion:
5-10 Days

Other Available Revisions for the IC200PWR101 IC200PWR101AIC200PWR101BIC200PWR101CIC200PWR101DIC200PWR101EIC200PWR101FIC200PWR101GIC200PWR101HIC200PWR101IIC200PWR101JIC200PWR101KIC200PWR101LIC200PWR101-LTIC200PWR101MIC200PWR101NIC200PWR101OIC200PWR101PIC200PWR101QIC200PWR101RIC200PWR101SIC200PWR101TIC200PWR101UIC200PWR101VIC200PWR101WIC200PWR101XIC200PWR101YIC200PWR101Z

Common misspellings:
  • 1C200PWR101
  • IC2o0PWR101
  • IC20oPWR101
  • IC200PWRl01
  • IC200PWR1o1
  • IC200PWR10l
  • IC200PWR101

Product Description


Made by GE Fanuc, the IC200PWR101 is a VersaMax power supply module. This product is intended to provide power to various modules and devices mounted to the rack backplane such as central processing units, network interface units, and numerous types of I/O units. This module is capable of serving as both a primary and secondary power source. It functions as a secondary source when connected to a booster carrier. The IC200PWR101 uses alternating current for its input voltage and input power, unlike some other VersaMax power units, which primarily use direct current.



The IC200PWR101 still uses direct current for its output voltages, which are 5 volts DC and 3.3 volts DC. Output current for this device is a cumulative total of both the 5-volt and 3.3-volt output voltages, but the output current must not go above 1.5 amperes. The highest output current for the 3.3 voltage setting is 0.25 amperes. For the 5-volt setting, the highest output current is 1.5 amperes minus the current from the 3.3-volt setting.



Input voltage for the IC200PWR101 is determined by voltage range and jumper installation. If a jumper is installed, the input voltage can range from 85 volts to 132 volts AC, with 120 volts AC being nominal. If no jumper is installed, the input voltage can range from 176 volts to 264 volts AC, with 240 volts AC being nominal. The IC200PWR101 can operate at 120 volts AC without a jumper installed. Warning: Jumpers must not be used at 240 volts input voltage.



The IC200PWR101 has a holdup time of 20 milliseconds and a frequency range of 47-63 Hertz. Input power is 27 volt-amps. This device is protected against short circuits and overloads.

Technical Information

The IC200PWR101

The IC200PWR101

Troubleshooting IC200PWR101

Troubleshooting information is available on IC200PWR101's website page; it also includes a datasheet user-manual and a wiring diagram.

Price and Availability for IC200PWR101

Price for IC200PWR101 is available by calling 1-800-360-6802 or by filling out our "fast quote". PDF Supply has over 30 years of experience with PLCs and has experience with the GE Fanuc Versamax Series dating back to 1995. IC200PWR101 comes with a minimum 1 year PDF Supply warranty. Returns are accepted for most unopened items. It does require pre-approval and RMA.

Repair your IC200PWR101

PDF Supply can repair your IC200PWR101 in 3-5 business days. And PDF Supply stands by all of its repairs with a 2 year customer satisfaction warranty.
