IC200ALG322

★ ★ ★ ★ ★ Rated 4.7/5 Based on 3 ratings.

Rate your purchase of the IC200ALG322

SKU 2173143  UPC 0997103774252

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

Request a Quote for IC200ALG322

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

New

$646

8 In Stock

✓  2 Year PDF Supply Warranty

*Need a Specific Revision?

Ships .

New Surplus

$492

Save $154

5 In Stock

✓  3 Year PDF Supply Warranty

*What is New Surplus?

Ships .

Reman

$323

Save $323

3 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Repair Service

$259

Save $387

5-10 Days

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Repair Completion:
5-10 Days

Other Available Revisions for the IC200ALG322 IC200ALG322AIC200ALG322BIC200ALG322CIC200ALG322DIC200ALG322EIC200ALG322FIC200ALG322GIC200ALG322HIC200ALG322IIC200ALG322JIC200ALG322KIC200ALG322LIC200ALG322-LTIC200ALG322MIC200ALG322NIC200ALG322OIC200ALG322PIC200ALG322QIC200ALG322RIC200ALG322SIC200ALG322TIC200ALG322UIC200ALG322VIC200ALG322WIC200ALG322XIC200ALG322YIC200ALG322Z

Common misspellings:
  • 1C200ALG322
  • IC2o0ALG322
  • IC20oALG322
  • IC200A1G322
  • IC200ALG322

Product Description


The IC200ALG322 is a GE Fanuc Versamax Series analog output module designed with four analog voltage outputs with an output range of -10 to + 10VDC. The outputs require an external power supply. The IC200ALG322 module’s backplane consumes 5V output: 50mA maximum, and there is no thermal derating for this module.

Resolution for the IC200ALG322 module is mV equivalent to 16 counts. The recommended range of external supply is+18 to +30VDC (including ripple) with a current consumption of 160mA max with load current calculated. The outputs of the IC200ALG322 module with a jumper with no effort retain their last states or default if backplane power or communications are interrupted or the PLC is not operating. The outputs continue in their default or previous state until changed output data from the backplane is established by the module or until field power is detached. The CPU or Network Interface Unit performs intelligent processing functions for the IC200ALG322 module. The IC200ALG322 module will receive four words of analog output data.

The IC200ALG322 module is equipped with LED indicators. When user-side power for the analog field-side circuits is presented, indication is identified by the green FLD PWR LED. Once the IC200ALG322 module is presented with power from the backplane, the green OK LED will illuminate.

Technical Specifications

No. of channels: 4 single-ended, one group
Voltage Range:  +/- 10.24 VDC
Current Range: N/A
Update Rate: 0.3 ms
LED Indicators: FLD PWR, OK
Power Consumption:    50 mA from +5V bus





Troubleshooting

Troubleshooting IC200ALG322

Troubleshooting information is available on IC200ALG322's website page; it also includes a datasheet user-manual and a wiring diagram.

Repair your IC200ALG322

PDF Supply can repair your IC200ALG322 in 3-5 business days. And PDF Supply stands by all of its repairs with a 1 year customer satisfaction warranty.



Customer Questions and Answers

  • Question:  What is an IC200ALG322?  Answer:  The IC200ALG322 is a 4-Channel, 12-Bit, Voltage, -10 to +10 VDC, Analog Output module from the GE Fanuc Versamax Series.
  • Question:  What are some characteristics of the channels?  Answer:  There are 4 single-ended channels, all in one group.
  • Question:  What does the FLD PWR LED indicate?  Answer:  This LED indicates that field power is present.
  • Question:  What does the OK LED indicate?  Answer:  This LED indicates that backplane power is present.
  • Question:  What is the backplane current consumption?  Answer:  5V output: 50 mA maximum
  • Question:  What are the configuration parameters?  Answer:  Output default
  • Question:  What is the output voltage?  Answer:  +/- 10.24 VDC
  • Question:  What is the update rate per module?  Answer:  0.3 ms maximum
  • Question:  What is the output default?  Answer:  Hold Last State (default), 0 (configurable)
  • Question:  What should I do if my IC200ALG322 is not working properly?  Answer:  Your IC200ALG322 may need repair.

For more information on the IC200ALG322 4-Channel, 12-Bit, Voltage, -10 to +10 VDC, Analog Output Module of the GE Fanuc Versamax Series, please see the Datasheet User-Manual.
