GE / IP FANUC Series 90/30 In Stock
IC697CGR935
SKU 2172064 UPC 0799705795068
All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.
PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.
Other Available Revisions for the IC697CGR935 IC697CGR935-AAIC697CGR935-BAIC697CGR935-CBIC697CGR935-DBIC697CGR935-GBIC697CGR935-HBIC697CGR935-JBIC697CGR935-Programming SoftwareIC697CGR935-CAIC697CGR935-LTIC697CGR935-RR
Common misspellings:
- 1C697CGR935
- IC697CGR935
Technical Specifications for IC697CGR935
| Manufacturer | GE Fanuc |
|---|---|
| Series | Series 90-70 |
| Part Number | IC697CGR935 |
| Product Type | CPU |
| Memory Capacity | 1 MB |
| Memory Type | CMOS RAM |
| Current | 3.1 A |
| Temperature | 0 to 50 degrees Celsius |
| Communication | RJ 45 |
| Ports | 2 |
Product Description
The IC697CGR935 module is a one slot controller in the GE Fanuc series, which permits fluctuating point calculations mandatory for CPU redundancy applications. The IC697CGR935 module in the Redundancy System is used as the controller. There are two control methods to note when using the IC697CGR935. In the GHS process, several single bus networks with one redundant controller are used in each synchronized PLC. When using the GDB process, multiple I/O networks are used with single or double buses in each synchronized PLC. Each control method can be easily activated and used without difficulty.
Installation of the IC97CGR935 module should not be attempted without referring to the appropriate Programmable Controller Installation and Hot Standby CPU Redundancy Manual. The battery should be connected to one of the module’s battery connectors. The key switch should be positioned to MEMORY PROTECT OFF, and there should be no rack power. Once module is installed in slot 1 of rack 0, power is turned on. The top LED should blink indicating that the IC697CGR935 module is powered up. Once the diagnostic is finished effectively, the top left LED stays on while the second and third LED will be off. The MEMORY PROTECT LED which is the fourth LED, is off because the key switch is in off position. Programming is now ready for the CPU. The CPU can be programmed regardless of the placement of the key. Once the program has been confirmed, the toggle switch can be positioned in the appropriate operational mode.
Technical Specifications
| Module Type: | Single Slot CPU |
| Operating Temperature: | 0 to 60 deg C (32 to 140 deg F) |
| Battery Shelf Life: | 5 years at 20 deg C (68 deg F) |
| Inputs and Outputs: | 12K each (any mix) |
| Serial Ports: | 3 |
| Current Required: | 3.1 Amps nominal |
The GE Fanuc IC697CGR935 CPU controller comes with LED indicators to give the users quick status updates. The port LED indicators glow green when the cable connects to the corresponding ports. There is also an LED that shows the status of the processor along with the LED indicators on the bottom that show the I/O activity status. In addition to these LED indicators, there is a 3-position switch that corresponds to each of the indicators. In the top position, this switch is used to enable all of the output functions. All of the outputs are disabled when the switch is in the middle position, and when it is in the bottom position, it causes the CPU to exit the "Run" mode. The operating temperature of the IC697CGR935 CPU ranges from 0 to 50 degrees Celsius. If the temperature frequently exceeds 50 degrees Celsius, various forced cooling methods should be applied. This CPU controller module has an RJ 45 port that is used for communication and network connections.
Technical Information
Specifications
|
Battery Shelf life Memory retention |
5 years at 20o C (68o F) 6 months nominal without applied power. |
|
Current required from 5V bus |
3.1 Amps nominal |
|
Operating Temperature |
0 to 60oC (32oF to 140oF); 70 CFM forced air required 0 to 50oC (32oF to 122oF); without forced air |
|
Time of Day Clock accuracy Elapsed Time Clock (internal timing) accuracy |
" 3.5 seconds per day maximum " .01% maximum |
|
Serial Ports Port 1: RS-232 compatible Port 2: RS-485 compatible (optocoupler isolated) Port 3: RS-485 compatible (not isolated) |
Programmer Serial Attachment, or other serial devices. Protocols supported: SNP Slave only |
t Refer to GFK-0867B, or later for product standards and general specifications. For installations requiring compliance to more stringent requirements (for example, FCC or European Union Directives), refer to InstallationRequirements for Conformance to Standards.
Troubleshooting
Troubleshooting IC697CGR935
Troubleshooting information is available on IC697CGR935's website page; it also includes a datasheet user-manual and a wiring diagram.
Repair your IC697CGR935
PDF Supply can repair your IC697CGR935 in 3-5 business days. And PDF Supply stands by all of its repairs with a 1 year customer satisfaction warranty.
Redundant CPU Genius Dual Bus (GDB) Operation
Description
An anomaly may occur when trying to simulate a MANUAL,forced switch from the Primary to the Secondary CPU in the IC697CGR935 andIC697CGR772 based Redundant systems, configured for Genius Dual Bus mode (GDB) with or without a dual bus. If the %Q Output Shared Data is not properly set in the CPU configuration, it may seem that the Primary CPU is not relinquishing control of the outputs.
Resolution
Normally, the Primary's outputs will exercise control because the Genius devices "listen" to Genius Bus Controller (GBC) #31 when they are configured for Hot Standby operation. If the %Q Shared Data is properly configured, the output states will be sent to the backup CPU across the RCM/BTM link, insuring redundancy. A failure in the primary CPU will disable the outputs on its bus controller causing the Genius devices on the bus to "listen" to the outputs from GBC #30.
If a manual switch to the Secondary CPU is commanded, the output data now flows from the Secondary CPU to the Primary CPU across the RCM/BTM link. A redundant system configured for GDB mode leaves the outputs enabled on both the Primary and Secondary GBCs as long as the processors are in the RUN mode. What is actually occurring is that the Secondary CPU "controls" by sending its outputs back to the Primary CPU, where GBC #31 sends them out. If the %Q Shared data is not properly configured (or missing altogether), the Primary CPU receives no data from the Secondary CPU and the Primary CPU uses data from its own %Q output table.
Note: When manually forcing a "role-reversal" like this on a system operating in Genius Hot Standby (GHS), the system will indeed force a DISABLE on the Primary CPU GBC outputs, causing a control switch to the Secondary, which is a bit different than GDB operation. It is also not guaranteed to be "bumpless"during the switchover from Secondary CPU back to the Primary CPU.
Customer Questions and Answers
- Question: What is an IC697CGR935? Answer: The IC697CGR935 is a 96 MHz, 32-Bit, Floating Point Central Processing Unit from the GE Fanuc 90-70 Series.
- Question: What does an IC697CGR935 do? Answer: This unit is used as the controller in a CPU Redundancy system.
- Question: How many redundancy control methods can be configured using IC697CGR935? Answer: You can set up the configuration of IC697CGR935 in 2 methods.
- Question: What can I use for the programming and configuration of IC697CGR935? Answer: Programming and configuration can be completed through MS-DOS or Windows programming software in order to perform real time control of machines, processes, and material handling systems.
- Question: How does IC697CGR935 communicate with I/O and smart option (specialty) modules? Answer: IC697CGR935 communicates over the rack mounted backplane via the VME C.1 Standard format.
- Question: Which supported option modules are included in the list available to use? Answer: All IC697 LAN interface modules, several Coprocessor modules, the Bus Controller for IC660/IC661 I/O, Communications modules, and all of the IC697 family of discrete and analog I/O modules.
- Question: What should I do if my IC697CGR935 is not working properly? Answer: Your IC697CGR935 may need repair.
For more information on the IC697CGR935 96 MHz, 32-Bit, Floating Point Central Processing Unit of the GE Fanuc 90-70 Series, please see the Datasheet User-Manual.
