IC600YB902

★ ★ ★ ★ ★ Rated 4.4/5 Based on 10 ratings.

Rate your purchase of the IC600YB902
IC600YB902 In Stock! 24Vdc Sink Output Module (8 points) IC600Y IC600YB PDFsupply also repairs GE IP

SKU 2175052  UPC 081312690837

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

Surplus New

$314

1 In Stock

✓  3 Year PDF Supply Warranty

*What is Surplus New?

Ships .

Reman

$285

Save $29

40 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Other Available Revisions for the IC600YB902 IC600YB902AIC600YB902BIC600YB902CIC600YB902DIC600YB902EIC600YB902FIC600YB902GIC600YB902HIC600YB902IIC600YB902JIC600YB902KIC600YB902LIC600YB902MIC600YB902NIC600YB902OIC600YB902PIC600YB902QIC600YB902RIC600YB902-RRIC600YB902SIC600YB902TIC600YB902UIC600YB902VIC600YB902WIC600YB902XIC600YB902YIC600YB902Z

Common misspellings:
  • 1C600YB902
  • IC6o0YB902
  • IC60oYB902
  • IC600Y8902
  • IC600YB9o2
  • IC600YB902

24Vdc Sink Output Module (8 points) YB902 Series 6 Module Without Face Plate IC600 IC600YB

Technical Information

The IC600YB902 module is a GE Fanuc component that is made for programmable controller systems. This 24 Volts DC sink output module has an industrial design and small dimensions that reduce overall costs by not needing too much space for installation. The IC600YB902 output module is intended for rack installation. The supported racks are an I/O rack or a CPU rack (Model 60). The module requires the proper placement of DIP switches in order to have adequate communication between the output terminals on the module and program’s output numbers. The module has 8 available outputs and it allows for wiring with both #12 AWG and #14 AWG gauge wires.



The IC600YB902 module is made for industrial applications and operation in locations where the relative humidity levels are between 5 and 95% (non-condensing). The operating temperature range of the unit is 0 to 60 degrees Celsius or 32 to 140 degrees Fahrenheit. The module responds in 1 millisecond and it provides 2 output groups that include connections of the common high and neutral type. The IC600YB902 module features an inrush current of 7 Amps and a maximum steady state current of 2 Amps. Additionally, the module has a leakage of 5 milliamps at the specified operating temperature and it has a total on-state current of 16 Amps per module. In addition to that, the voltage drops up to 2.25 Volts when the unit is turned on. The IC600YB902 module has power requirements of 5 Volts DC with a current of 400 milliamps. The operating voltage ranges from 19 to 40 Volts DC.
