IC600YB805

★ ★ ★ ★ ★ Rated 4.6/5 Based on 12 ratings.

Rate your purchase of the IC600YB805
IC600YB805 230Vac/dc Input Module (8 points) IC600Y IC600YB PDFsupply also repairs GE IP FANUC PLC p

SKU 2173200  UPC 030419524743

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

Reman

$570

3 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Other Available Revisions for the IC600YB805 IC600YB805AIC600YB805BIC600YB805CIC600YB805DIC600YB805EIC600YB805FIC600YB805GIC600YB805HIC600YB805IIC600YB805JIC600YB805KIC600YB805LIC600YB805MIC600YB805NIC600YB805OIC600YB805PIC600YB805QIC600YB805RIC600YB805-RRIC600YB805SIC600YB805TIC600YB805UIC600YB805VIC600YB805WIC600YB805XIC600YB805YIC600YB805Z

Common misspellings:
  • 1C600YB805
  • IC6o0YB805
  • IC60oYB805
  • IC600Y8805
  • IC600YBb05
  • IC600YB8o5
  • IC600YB805

230Vac/dc Input Module (8 points) YB805 GE Series Six Module Without Face Plate IC6 IC600YB

Technical Information

The IC600YB805 input module is a 230 Volts AC/DC receiver input module that comes with 8 input points. It is a GE Fanuc Series Six module without a faceplate. The operators can use the IC600YB805 input receiver module in any I/O racks except the first rack in a remote I/O station. The IC600YB805 receiver module is essential for providing an interface for the address, data, and control signals that are exchanged between the Series Six Central Processor Unit (CPU) and the I/O modules. The IC600YB805 receiver input module also provides you with a link in a daisy chain to other I/O racks. The GE Fanuc IC600YB805 receiver input module monitors 3 types of error conditions. These conditions are errors in the daisy-chain power and the continuity of the I/O racks downstream (a “Chain OK” error), errors in the parity of the data output by CPU (a “Local Parity” error), and errors in the parity of CPU output data that is driven by an I/O transmitter module as detected by other I/O receiver modules downstream (a “Chain Parity” error).



The GE Fanuc Series Six IC600YB805 receiver input module comes with several LED indicators that are visible through a clear protective plastic lens on the module faceplate. The LED indicators on the module include 1 LED for each input that turns on when the module detects errors at the inputs and these LEDs are also suitable aids for troubleshooting. At purchase, the GE Fanuc IC600YB805 receiver input module comes from the factory configured for installation in all intermediate I/O racks in the daisy chain. However, if the users want to install the module at the end of the I/O station daisy chain, they must reconfigure the IC600YB805 receiver input module first. Reconfiguring the receiver module will ensure the proper termination of the I/O Bus after its installation at the end of the I/O station’s daisy chain setup.
