IC600BF806

★ ★ ★ ★ ★ Rated 4.6/5 Based on 7 ratings.

Rate your purchase of the IC600BF806
IC600BF806 In Stock! 12Vac/dc Input Module (8 points) IC600BF IC600B PDFsupply also repairs GE IP FA

SKU 2175323  UPC 0416500574727

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

New

$995

2 In Stock

✓  2 Year PDF Supply Warranty

*Need a Specific Revision?

Ships .

New Surplus

$722

Save $273

1 In Stock

✓  3 Year PDF Supply Warranty

*What is New Surplus?

Ships .

Reman

$570

Save $425

7 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Other Available Revisions for the IC600BF806 IC600BF806AIC600BF806BIC600BF806CIC600BF806DIC600BF806EIC600BF806FIC600BF806GIC600BF806HIC600BF806IIC600BF806JIC600BF806KIC600BF806LIC600BF806MIC600BF806NIC600BF806OIC600BF806PIC600BF806QIC600BF806RIC600BF806-RRIC600BF806SIC600BF806TIC600BF806UIC600BF806VIC600BF806WIC600BF806XIC600BF806YIC600BF806Z

Common misspellings:
  • 1C600BF806
  • IC6o0BF806
  • IC60oBF806
  • IC6008F806
  • IC600BFb06
  • IC600BF8o6
  • IC600BF806

12Vac/dc Input Module (8 points) GE Fanuc Series Six Board with Face Plate IC600BF IC600B

Technical Information

The GE Fanuc IC600BF806 input module is a 12 Volts AC/DC input module. Four different types of AC/DC input modules are available from GE Fanuc including the 12 Volts AC/DC, 24 to 48 Volts AC/DC, 115 Volts AC/DC, and the 230 Volts AC/DC rated input module versions. The IC600BF806 input module has a total of 8 inputs and it is designed for use with the GE Series Six PLCs. This input module can detect bipolar DC and AC voltages which are supplied by user devices such as limit switches, relays, cam switches, and toggle switches. The inputs on the IC600BF806 input module are split into 2 independent groups with a separate neutral point for each group.



LEDs are provided for all the input circuits on the IC600BF806 input module to provide a visual indication of the circuit activity. Each input circuit consists of 4 components that are a rectifier, a Schmitt trigger, a noise filter, and an opto-isolator. The input circuit “on” range for the IC600BF806 module is 10 to 20 Volts AC/DC and the input “off” range is 0 to 4 Volts AC/DC. The input load is 1 kiloohm (7 milliamps at 12 Volts). The rated “off” delay is 20 to 50 milliseconds and the “on” delay is 10 to 20 milliseconds. At 5 Volts DC, the IC600BF806 module draws a maximum current of 104 milliamps. The circuit board dimensions are 8.15 x 11 inches and the faceplate dimensions are 12.46 x 1.175 inches. The temperature outside the rack containing the IC600BF806 module should be maintained between 0 and 60 degrees Celsius.
