Terminal Assembly for 6241BP10812

Technical Information

The ABB 6241BP10832 unit is a terminal assembly. The 6241BP10832 terminal assembly can be used with the I/O block with the catalog number 6241BP10812 which is a 5, 12, or 24 Volts DC rated sink module. The second component of the 6241BP10812 block is an electronics assembly which has the catalog number 6241BP10822. A sink block such as the 6241BP10812 block provides current to connected field output devices. The I/O block operates at nominal voltage range of 12 to 24 Volts DC, and can also be made TTL compatible by using a 5 Volts supply and connecting a jumper between terminals 5 and 6. Output devices are connected between the channel terminal and the positive side of the power supply. Input devices are connected between the channel terminal and the negative side of the power supply.



The 14 AWG wire can be used for terminations for all the power terminals and channels on the 6241BP10812 block and its components such as the 6241BP10832 terminal assembly. The I/O block has 32 discrete output and input circuits with individual logic side indicators for each circuit. The typical current draw of the block is 150 milliamps which can go up to a maximum value of 300 milliamps. The operating voltage range is 10 to 30 Volts DC with a 12/24 Volts nominal supply and 4.75 to 5.25 Volts DC with a 5 Volts supply. The module weighs 4 pounds. The I/O block dissipates up to 18 Watts as heat when all 32 outputs are active at 0.5 Amps and it dissipates a minimum of 11 Watts with 8 active inputs. The working temperature range for the I/O block and its components like the 6241BP10832 terminal assembly is 32 to 140 degrees Fahrenheit.
