6241BP10812

★ ★ ★ ★ ★ Rated 4.4/5 Based on 13 ratings.

Rate your purchase of the 6241BP10812
ABB Taylor Mod 300 | 623 624 Series | 6241BP10812 | Image

SKU 2176013  UPC 0218725090996

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

Reman

$2286

56 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Repair Service

$1829

Save $457

5-10 Days

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Repair Completion:
5-10 Days

Other Available Revisions for the 6241BP10812 6241BP10812A6241BP10812B6241BP10812C6241BP10812D6241BP10812E6241BP10812F6241BP10812G6241BP10812H6241BP10812I6241BP10812J6241BP10812K6241BP10812L6241BP10812M6241BP10812N6241BP10812O6241BP10812P6241BP10812Q6241BP10812R6241BP10812S6241BP10812T6241BP10812U6241BP10812V6241BP10812W6241BP10812X6241BP10812Y6241BP10812Z

Common misspellings:
  • 62A1BP10812
  • 624lBP10812
  • 62418P10812
  • 6241BPl0812
  • 6241BP1o812
  • 6241BP10b12
  • 6241BP108l2
  • 6241BP10812

ABB Block 5/12/24Vdc Sink I/O Block 32 Circuits

Technical Information

The ABB 6241BP10812 I/O block is a complete 5, 12, or 24 Volts DC rated sink I/O block. This I/O block is made up of 2 main components which are a terminal assembly and an electronics assembly. The field wiring connects to the terminal assembly, which enables the replacement of the electronics assembly without requiring any changes to the field wiring. The configuration of the I/O block is stored in the electronics assembly. There are a total of 32 circuits on the 6241BP10812 I/O block which can be configured as discrete inputs or as discrete outputs. The environmental specifications for the 6241BP10812 I/O block include a storage temperature range of -40 to 212 degrees Fahrenheit and a working temperature range of 32 to 140 degrees Fahrenheit. The relative humidity level should be kept between 5 and 95%.



The weight of the 6241BP10812 I/O block is approximately 1.8 kilograms. The 6241BP10812 I/O block can be operated at voltage ranging from 10 to 30 Volts DC. The 6241BP10812 I/O block also supports a 5 Volts power supply with a 4.75 to 5.25 Volts DC voltage range. The 6241BP10812 I/O block has typical and maximum current consumption ratings of 150 milliamps and 300 milliamps, respectively. The input characteristics for the circuits configured as inputs include 3.3 kiloohms of input impedance, 1 millisecond of input processing time, and selectable input filter times ranging from 1 to 100 milliseconds. The output characteristics include 0.5 Amps per circuit of steady state output current, a maximum inrush current of 4 Amps for 10 seconds duration, a maximum circuit overcurrent threshold of 5 Amps and a total block output current of 16 Amps. The wire size recommended for the power and terminal wiring is 14 AWG.
