ABB Taylor Mod 300 | 623 624 Series | 6241BP10411 | Image

SKU 2171121  UPC 0505302265602

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

Reman

$1136

74 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Repair Service

$909

Save $227

5-10 Days

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Repair Completion:
5-10 Days

Other Available Revisions for the 6241BP10411 6241BP10411A6241BP10411B6241BP10411C6241BP10411D6241BP10411E6241BP10411F6241BP10411G6241BP10411H6241BP10411I6241BP10411J6241BP10411K6241BP10411L6241BP10411M6241BP10411N6241BP10411O6241BP10411P6241BP10411Q6241BP10411R6241BP10411S6241BP10411T6241BP10411U6241BP10411V6241BP10411W6241BP10411X6241BP10411Y6241BP10411Z

Common misspellings:
  • 62A1BP10411
  • 624lBP10411
  • 62418P10411
  • 6241BPl0411
  • 6241BP1o411
  • 6241BP10A11
  • 6241BP104l1
  • 6241BP1041l
  • 6241BP10411

Block 12/24Vdc Source I/O 32 Circuits

Technical Information

The ABB 6241BP10411 block is a complete I/O block with a terminal assembly and an electronics assembly. The 6241BP10411 I/O block is rated for 12/24 Volts DC and it is a source I/O block designed to provide current to field devices. The block comes with 32 circuits which can be configured to accept discrete inputs or to provide discrete outputs. With a single source, the operating voltage range is 10 to 30 Volts DC with 10% allowable ripple. The 6241BP10411 I/O block typically requires 150 milliamps of current which can go up to a maximum of 300 milliamps. The power supply dropout times are 4 milliseconds and 20 milliseconds at 12 Volts and 24 Volts, respectively. One LED is provided on the 6241BP10411 I/O block to indicate the unit’s status.



A separate LED is provided on the block to indicate the I/O status. Additionally, each circuit on the block comes with logic side indicators. The block to block isolation rating is 1500 Volts.  The insulation on the 6241BP10411 I/O block has a minimum resistance of 2.2 megaohms. ABB recommends 14 AWG wire for the terminal wiring and for the power wiring. The shipping weight of the I/O block is approximately 4 pounds. With 8 active inputs, the heat dissipation for the 6241BP10411 I/O block is 11 Watts and with 32 active outputs sourcing 0.5 Amps of current each, the heat dissipation can reach a maximum of 18 Watts. The temperature of air surrounding an operating 6241BP10411 block should not exceed 140 degrees Fahrenheit. Unused 6241BP10411 blocks should be kept in an area where the temperature is maintained between -40 and 212 degrees Fahrenheit. The relative humidity around the unit should be between 5 and 95%.
