6240BP10821

★ ★ ★ ★ ★ Rated 4.6/5 Based on 13 ratings.

Rate your purchase of the 6240BP10821
ABB Taylor Mod 300 | 623 624 Series | 6240BP10821 | Image

SKU 2174100  UPC 0969720831489

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

Reman

$906

88 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Repair Service

$725

Save $181

5-10 Days

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Repair Completion:
5-10 Days

Other Available Revisions for the 6240BP10821 6240BP10821A6240BP10821B6240BP10821C6240BP10821D6240BP10821E6240BP10821F6240BP10821G6240BP10821H6240BP10821I6240BP10821J6240BP10821K6240BP10821L6240BP10821M6240BP10821N6240BP10821O6240BP10821P6240BP10821Q6240BP10821R6240BP10821S6240BP10821T6240BP10821U6240BP10821V6240BP10821W6240BP10821X6240BP10821Y6240BP10821Z

Common misspellings:
  • 62A0BP10821
  • 624oBP10821
  • 62408P10821
  • 6240BPl0821
  • 6240BP1o821
  • 6240BP10b21
  • 6240BP1082l
  • 6240BP10821

Electronic Assembly for 6240BP10811

Technical Information

The electronic assembly with the product code 6240BP10821 is part of the Trio I/O system that is designed and manufactured by ABB/Taylor. The electronic assembly is intended for use with an I/O block with the product code 6240BP10811 and it is made to be part of this 16-circuit block along with the terminal assembly. The 6240BP10821 electronic assembly is made for DC power sources with an input voltage of 24/48 Volts AC and a current range from 150 to 300 milliamps. The block itself has a weight of 1.8 kilograms (4 pounds) and dimensions that include a height of 224 millimeters (8.8 inches), a width of 88 millimeters (3.5 inches), and a depth of 100 millimeters (3.9 inches).



The 6240BP10821 block electronic assembly has a specified operating temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). In addition to that, the unit can be stored at a temperature range of -40 to 100 degrees Celsius (-40 to 212 degrees Fahrenheit). The block can endure a vibration of 5 to 20 Hertz with 5.08 millimeters (0.2 inches) of displacement and a vibration of 10 to 200 Hertz at 1G. The 6240BP10821 electronic assembly for Model 300 blocks comes with individual LED indicators for each circuit and it dissipates 68.8 Watts of energy as heat. The unit has a block to block isolation rating of 1500 Volts and it features selectable input filter times of 5 to 100 milliseconds. The 6240BP10821 electronic assembly has a typical input processing time of 1.7 milliseconds and an input impedance of 5.6K Ohms. The maximum inrush current of the block is 10 Amps for up to 10 milliseconds and its output current for steady state operation is 2 Amps per circuit.
