6236BP10820

★ ★ ★ ★ ★ Rated 4.7/5 Based on 8 ratings.

Rate your purchase of the 6236BP10820
ABB Taylor Mod 300 | 623 624 Series | 6236BP10820 | Image

SKU 2170022  UPC 0319801913823

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

Reman

$684

8 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Repair Service

$548

Save $136

5-10 Days

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Repair Completion:
5-10 Days

Other Available Revisions for the 6236BP10820 6236BP10820A6236BP10820B6236BP10820C6236BP10820D6236BP10820E6236BP10820F6236BP10820G6236BP10820H6236BP10820I6236BP10820J6236BP10820K6236BP10820L6236BP10820M6236BP10820N6236BP10820O6236BP10820P6236BP10820Q6236BP10820R6236BP10820S6236BP10820T6236BP10820U6236BP10820V6236BP10820W6236BP10820X6236BP10820Y6236BP10820Z

Common misspellings:
  • 62368P10820
  • 6236BPl0820
  • 6236BP1o820
  • 6236BP10b20
  • 6236BP1082o
  • 6236BP10820

Electronic Assembly for 6236BP10810

Technical Information

The 6236BP10820 Electronics Assembly belongs to the TRIO series of I/O devices made by ABB. It contains the microprocessor of the I/O block and it offers advanced communication and mathematical capabilities. Some of the diagnostics facilities offered by this module include over-range detection, under range detection, and feedback error diagnostics. The 6236BP10820 Electronics Assembly also ensures 0.15% output accuracy and 6 microamps of output resolution with 25 milliseconds of output update frequency. This module can be grounded by connecting to the terminal block of the system while ensuring proper contact between 2 assemblies. It has the responsibility to drive the indicator LEDs of the I/O device.



The 6236BP10820 Electronics Assembly can be removed by using a block puller in 3 steps. First, open the door of the module. Second, align the electronic assembly. Finally, push the assembly down firmly and quickly to tighten the retaining screws. The assembly is a highly reliable, field-mounted device which acts as the intelligent module in a complex I/O system. It helps to collect the large number of I/O points that are located remotely in a large plant and to manage and communicate the data between the devices within the system. It ensures communication with up to 30 connected blocks via the system field buses. The 6236BP10820 Electronics Assembly can be removed without disturbing the field wiring as it is a removable device. When selecting an enclosure for the module, make sure to check whether the space provided around the device is enough to allow for the free flow of air to cool the module down.
