6235BP10810

★ ★ ★ ★ ★ Rated 4.9/5 Based on 6 ratings.

Rate your purchase of the 6235BP10810
ABB Taylor Mod 300 | 623 624 Series | 6235BP10810 | Image

SKU 2171256  UPC 0890892383684

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

Reman

$1136

16 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Repair Service

$909

Save $227

5-10 Days

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Repair Completion:
5-10 Days

Other Available Revisions for the 6235BP10810 6235BP10810A6235BP10810B6235BP10810C6235BP10810D6235BP10810E6235BP10810F6235BP10810G6235BP10810H6235BP10810I6235BP10810J6235BP10810K6235BP10810L6235BP10810M6235BP10810N6235BP10810O6235BP10810P6235BP10810Q6235BP10810R6235BP10810S6235BP10810T6235BP10810U6235BP10810V6235BP10810W6235BP10810X6235BP10810Y6235BP10810Z

Common misspellings:
  • 62358P10810
  • 6235BPl0810
  • 6235BP1o810
  • 6235BP10b10
  • 6235BP108l0
  • 6235BP1081o
  • 6235BP10810

Block 24/48Vdc Analog Current Source 6 Inputs 4-20ma

Technical Information

The 6235BP10810 block has been manufactured by GE Fanuc as a current source input block. It is an analog current source block that features 6 inputs. The 6235BP10810 input block is also a DC-powered block that is rated at 24/48 Volts DC. It dissipates up to 12 Watts of heat when it operates, and it can operate safely within a temperature range of 32 to 140 degrees Fahrenheit (0 to 60 degrees Celsius). When not in use, the 6235BP10810 input block can be stored in an environment with a temperature range of -40 to 212 degrees Fahrenheit (-40 to 100 degrees Celsius). In both operation and in storage, this current source input block can tolerate a relative humidity range of 5 to 95% as long as the humidity does not condense.



The GE Fanuc 6235BP10810 current source input block weighs 4 pounds (1.8 kilograms) and it measures 8.83 x 3.5 x 3.94 inches (22.44 x 8.89 x 10 centimeters) in its dimensions. It has 2 LEDs which are the “Unit OK” LED and the “I/O Enabled” LED. The “Unit OK” LED indicates that the input block is operating normally and the “I/O Enabled” LED lets the operators know whether or not the inputs on the block are active. Each of the 6 inputs on the 6235BP10810 input block comes with an independent power source that is a 24 Volts rated current loop power supply that can provide a connected device with up to 25 milliamps of current.
