6230BP10810

★ ★ ★ ★ ★ Rated 4.6/5 Based on 9 ratings.

Rate your purchase of the 6230BP10810
ABB Taylor Mod 300 | 623 624 Series | 6230BP10810 | Image

SKU 2175206  UPC 0682513863442

All product names, trademarks, brands and logos used on this site are the property of their respective owners. PDF Supply is not an authorized distributor, reseller or representative of the products featured on this website. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to in indicate any affiliation with or authorization by any rights holder.

PDF Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with PDF Supply's 1-year, 2-year, or 3-year warranty.

Reman

$561

164 In Stock

✓  2 Year PDF Supply Warranty

*What is Remanufactured?

Ships .

Repair Service

$449

Save $112

5-10 Days

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Repair Completion:
5-10 Days

Other Available Revisions for the 6230BP10810 6230BP10810A6230BP10810B6230BP10810C6230BP10810D6230BP10810E6230BP10810F6230BP10810G6230BP10810H6230BP10810I6230BP10810J6230BP10810K6230BP10810L6230BP10810M6230BP10810N6230BP10810O6230BP10810P6230BP10810Q6230BP10810R6230BP10810S6230BP10810T6230BP10810U6230BP10810V6230BP10810W6230BP10810X6230BP10810Y6230BP10810Z

Common misspellings:
  • 623oBP10810
  • 62308P10810
  • 6230BPl0810
  • 6230BP1o810
  • 6230BP10b10
  • 6230BP108l0
  • 6230BP1081o
  • 6230BP10810

Block 24/48Vdc Analog 4 Inputs / 2 Outputs 6 points

Technical Information

The 6230BP10810 Analog I/O Block is a 4-input and 2-output standard TRIO analog I/O block that is manufactured by GE Fanuc. It uses a 24 Volts DC or 48 Volts DC rated power supply to operate. The inputs of the analog I/O block are numbered as inputs 1 through 4 and the remaining 2 terminals are the outputs, which are numbered as outputs 1 and 2. The 6230BP10810 Analog I/O Block has 2.2 megaohms of insulation resistance and 1500 Volts of block to block isolation. The characteristics of the input channels include 12 bits of input resolution, 4 milliseconds of input update frequency, and input diagnostics functions.



The 6230BP10810 Analog I/O Block has 5 operating ranges for the input channels which are 0 to 10 Volts DC, -10 to 10 Volts DC, -5 to +5 Volts DC, 0 to 5 Volts DC, and 1 to 5 Volts DC. It has an analog to digital converter which is shared by the inputs. The analog to digital converter has the responsibility to convert input voltage values into the range of -4095 to +4095. This block also has input filters for filtering the analog voltage before sending it to the analog to digital converter. The LED indicators of the module, which are the “Unit OK” and “I/O Enabled” LEDs, indicate the visible status of the devices. The 6230BP10810 Analog I/O Block has 6 Watts of rated heat dissipation. It can provide the inputs and outputs in engineering units and the 16-bit two's-complement format. The input and output values can be displayed as a whole integer value by using a compatible handheld monitor.
